Name: Fisher 205 Rare Vintage AM-FM Stereo Receiver with FM Antenna No Manual
Brand: Fisher
SKU: 418070613111
Price: 132.0 USD
Availability: InStock
Rating: 4.6850000000000005 (899 reviews)

Description

This vintage Fisher 205 AM-FM stereo receiver is a rare find for any audiophile. With a peak power output of 56 watts and a signal-to-noise ratio of 65 dB, this receiver offers impressive sound quality. The receiver features a high filter, FM muting, and spurious selection of 75 dB to ensure clear and accurate tuner reception. In addition to the FM and MW tuner frequencies, this receiver also has aux and tape inputs and outputs, a headphone jack, and a tape rec DIN output. The Fisher 205 is a two-channel receiver with a channel separation of 65 dB and a total harmonic distortion of 0.5%. This vintage audio and video receiver is a must-have for any collector.

Specifics

AM suppression	56 dB
Attenuation factor	50
Aux 1 & 2 inputs	200 mV / 100k ohms
Bass Control	± 10 dB at 100 Hz
Brand	Fisher
Channel separation	65 dB
Co-wave selection	1.2 dB
Depth	14 inches
FM mono	0.9 µV
FM muting	Yes
FM stereo	4.0 µV
Frequency response	10 Hz - 50 KHz
Headphone Jack	Yes
Headphones Output	5 V, 100 ohm
High Filter	Yes
IF attenuation	80 dB
Image frequency attenuation	56 dB
LW Distortion Factor	700 µV
Loudness Control	+ 8 dB at 100 Hz, + 4 dB at 10 kHz
MPN	14496
MW	300 µV
Midrange Control	± 5 dB at 1 kHz
Model	FISHER 205
Number of Channels	2
Peak power output	56 watts
Phono Input	2.5 mV / 50k ohms
Power Per Channel RMS	28 Watts / Channel @ 8 Ω
Selectivity	65 dB
Signal-to-noise ratio	Mono: 65 dB / Stereo: 60 dB
Signal-to-noise ratio - Phono	65 Db
Signal-to-noise ratio - Tape, Aux	85 dB
Spurious selection	75 dB
Tape Out Front	6.3 mm jack plug
Tape Play DIN Input	200 mV / 100k ohms
Tape Play Input	200 mV / 100k ohm
Tape Rec DIN Output	4 mV / 10k ohms
Tape Rec Output	210 mV / 2.2k ohms
Total Harmonic Distortion	0.5 %
Treble Control	± 10 dB at 10 kHz
Tuner Capture ratio	4 dB
Tuner Frequencies	FM: 87.5 - 108 MHz / MW: 520 - 1605 kHz LW: 150 - 350 kHz
Tuner Reception	FM, MW, LW
Weight	23.5 lbs.
Width	17-1/2 inches
